Textile Heat Resistant Conveyor Belt

Basic Info.

Model NO.	EP100~EP400, NN100~NN400 etc
Performance	Automotive Sealing Strip
Material	Strong Rubber Conveyor Belt
Application	Cement, Coal Mine, Quarry, Steel, Iron etc
Supply Ability	10000 Meter Per Month
Transport Package	International Packing
Specification	ISO, CE OR OEM
Trademark	SHUOLONG
Origin	Shandong, China
HS Code	40101200
Production Capacity	20000meter/Month

Product Description

Heat Resistant Ep Fabric Conveyor Belt

Product Desription

Heat resistant conveyor belt is mainly used to transport high temperature materials, such as sintering ore, hot coke, clinker, hot casting and so on. According to the manifestation of the heat resistant belt breakage until to lose transportation ability and the heat resistant grading, we use EDPM or SBR as the covering layer rubber, and high modulus low shrinkage polyester or cotton canvas as the strong layer. It can use the heat resistant woven glass fabric between the cover rubber and the layers, so as to improve the working life of the heat resistant conveyor belt. We can make it into endless conveyor belt as per cllients' requirement.

The heat resistance conveyor belt physical property of the cover rubber after heat test shall conform to the values specified in the table.

1. Specification

Rubber conveyor belt1.Ply:1-10plies2.Width:120-2200mm3.Thickness: 6-40mm4. Cover Tensile Strength: 9-25MPA Specifiction/strength:160N/mm-----3150N/mmWidth:100mm---2200mmEp80 Ep100 Ep125 Ep200 Ep250 Ep300 Ep400 Ep500 Ep600NN80 NN100 NN125 NN200 NN250 NN300 NN400 NN500 NN600Advantage:1. Natural rubber Thin belt body with high strength, light weight.2. Anti-abrasive, impact resistant, corrosion resistant3. Softy belt body, good flexibility, excellent trough.4. Vulcanization molding 5. Long service lifeFeatures1.Excellent elasticity2.Anti-impact3.High-adhesion4.Good flexibility5.Trough ability6.Better stability of size7.Resistance to water

Applicationrubber conveyor belt is widely used in Harbour (port), Metallurgy, Mining, Electricity, Coal, Foundries, Construction, Food, Cement, Fertilizer, Copper, Pig Iron Ores, Sponge Iron Reserves etc. rubber conveyor belt has over 10 key types according to the use classification:

1. Flat normal type
2. Chevron Pattern type
3. V-belt pattern type
4. Nylon casing ply type
5. Heat /cold resistant type
6. Oil resistant type
7. Flame resistant type ( self- extinguishing type)
8. Chemical resistant type
9. Anti shock type
10. Anti-abrasive type

conveyor belt are primarily used in the following industries:

• Chemical industry
• Coal-fired power stations
• Iron and steel industry
• Quarries
• Recycling industry
• Sand and gravel industry
• Metallurgy
• Agriculture
• Cargo terminal and port
• Architecture field
• Logistics and other fields

Application

The physical and mechanical properties of the heat resistant covering layer after tested should be in accordance with the following table:
Project		The type
		T1	T2	T3	T4
		Change the range
Hardness	Draw the intensity	20	20	20	20
	Maximum after wearing out	85
Draw the intensity	The minimum value Mpa after wearing out	12	10	5	5
	Performance rate of change /%	-25	-30	-40	-40
Break person who extend	Performance rate of change /%	-50	-50	-55	-55
	After aging rate of change /%	200	200	180	180

Item		type
		type I		type II		type III
		variable range
Hardness	Difference before and after ageing (IRHD)	±20
	Max. Value after ageing (IRHD)	85
Tensile strength	variable rate in performance <=	25		30		40
	Min. value after ageing Mpa	12		10		5
Rate of elongation at break	variable rate in performance% <=	50				55
	Min. value after ageing	200				180

The heat resistance conveyor belt abrasive wear of the cover rubber

Type Item level	Abrasive wear
	type I	type II	type III
First quality	0.8	1	1
accepts	1	1.2	1.2

The heat resistance conveyor belt layer to layer adhesion strength

Item	interlayer of cloth	cover layer and cloth interlayer
		Thickness of the cover layer ≤1.5mm	Thickness of the cover layer >1.5mm
The average value of the longitudinal specimen shall be no less than	3	2.2	2.6
The peak value of the longitudinal specimen	2	1.6	2.0

Belt width (mm)	Sidewall height (mm)	Cleat height (mm)	Effective belt width (mm)
400	60		-
	80	70
	100	90
	120	100
500	60		250
	80	70
	100	90
	120	110
	160	140
650	60		250, 300, 350
	80	70
	100	90
	120	110
	160	140
	200	180
800	60		350, 410, 460
	80	70
	100	90
	120	110
	160	140
	200	180
	240	220
1000	60		460, 550, 640, 690,
	80	70
	100	90
	120	110
	160	140
	200	180
	240	220
	300	270
1200	60		460, 550, 640, 690
	80	70
	100	90
	120	110
	160	140
	200	180
	240	220
	300	270

Standards		Cover Rubber			Adhesion
		Tensile Strength	Elongation at break	Abrasion	Cover to Ply		Cover to Ply
DIN 22102		Mpa	%	mm3	N/mm		N/mm
					(<=1.5mm)		(>1.5mm)
DIN 22102-Z		15	350	250	3.5		4.5
DIN 22102-W		18	400	90	3.5		4.5
DIN 22102-Y		20	400	150	3.5		4.5
DIN 22102-X		25	450	120	3.5		4.5
Standards	Cover Rubber			Adhesion
	Tensile StrengTD	Elongation at break	Abrasion	Cover to Ply	Cover to Ply	Ply to Ply
AS 1332	Mpa	%	mm3	N/mm	N/mm	N/mm
				(<=1.9mm)	(>1.9mm)
AS 1332-N17	17	400	200	4	4.8	6
AS 1332-M24	24	450	125	4	4.8	6
Standards	Cover Rubber			Adhesion
	Tensile StrengTD	Elongation at break	Abrasion	Cover to Ply	Cover to Ply	Ply to Ply
RMA	Mpa	%	mm3	N/mm	N/mm	N/mm
				(<=1.6mm)	(>1.6mm)
RMA-I	17	400		3	4.4	4
RMA-II	14	400		3	4.4	4
Standards	Cover Rubber			Adhesion
	Tensile StrengTD	Elongation at break	Abrasion	Cover to Ply	Cover to Ply	Ply to Ply
SANS 1173	Mpa	%	mm3	N/mm		N/mm
A	18	400	70	5		7
C	20	400	150	5		7
M	25	450	120	5		7
N	17	400	150	5		7

Specification:1) Fabric code: EP100~EP400, NN100~NN400, TN/C & CC

2) No.s of ply: 1~10 3) Width: 300~2000mm 4) Thickness: 6~30mm 5) Delivery time: 20~30 day for general orders
Characteristics:
Classify by varying heat resistant degree: Type T1: To stand a testing temperature≤100°C; Type T2: To stand a testing temperature≤125°C; Type T3: To stand a testing temperature≤150°C; Type T4: To stand a testing temperature≤175°C. Classify by structure: Type 1: Same as general use conveyor belt, composed of carcass and cover rubber on top and bottom sides.Type 2: With an additional insulation layer between crubber cover and carcass.

1. Belt body light and thin, 2. High tensile strength, 3. Moisture resistant, 4. Fatigue resistant, 5. Impact resistant, 6. Excellent trough ability, 7. Good thermal stability etc.Advantage:1. Thin belt body with high strength, light weight.2. Anti-abrasive, impact resistant, corrosion resistant3. Softy belt body, good flexibility, excellent trough.4. Vulcanization molding 5. Long service life

Application:

Widely used in metallurgy, building material and foundry industries, to convey sintered-ores.
Standards offeredGB/T9784, DIN22102, BS490, AS1332, RMA, JISK6322, SABS1173 etc.

Why choose us?1. High level of choosing upstream supplier: like carcass, Wuxi Taiji being our strategic partner supplying qualified fabric. All raw materials purchase is accompanied with quality test certificate. 2. Strict QC system over the whole process of production: raw materials - semi-finished product - finished product Every one step of semi-finished product shall be tested before next step of processing. Unqualified pieces are now allowed for next step of processing. 3. All finished products shall get tested, and onlt qualified products can leave factory.
