Basic Info.

Model NO.	Open V type
Usage	Coating with Adhesive Tape
Performance	Strong Rubber Conveyor Belt
Color	Black
Width	350-2200mm
Fabric	Ep
Transport Package	International Packing
Specification	ISO, CE OR OEM
Trademark	SHUOLONG
Origin	Shandong, China
HS Code	401012
Production Capacity	20000meter/Month

Product Description

Quality Assured Special Pattern Chevron Rubber Conveyor Belt Huayue Cc Nn Ep St (B400-2200)

Product Desription

1. Specification

2. Physical Properties of Rubber Cover (before aging) DIN22102,GB/T7984 Standard

Rubber of DIN 22131 (K grade) is suitable for flame resistant steel cord conveyor belts.

3. Ply Adhesion

Application

Pattern conveyor belt (chevron conveyor belt) is suitable for transporting powdery, granular and little lump materials at angle 0~40 degree. Pattern shape can be made as per clients' requirement with different pattern height.


Why Choose Us

1. Certificate

2. R&D Center and Testing Lab

Packing & Shipping

FAQ
Q1. Are you a manufacturer?
A. Yes, we have been producing and selling conveyor belts since 2009.

Q2. Can you produce belts with my own brand?
A. Yes, we can.

Q3. What about the lead time?
A. 1) 5~7 days for sample (free sample)
2) 15~30 days according to order quantity

Q4. How about payment terms?
A. 1) We prefer T/T, 30% advance paid upon order, rest upon b/l copy, or
2) Sight or deferred L/C, or
3) Other payment terms approved.

Q5. How do you ensure product quality?
A. 1) We have a R&D center of an independent design and developing capacity
2) We an independent testing laboratory with full-property testing capacity of conveyor belt. We can test various materials, rubber, fabric, semi-finished product and finished product.

Fabric Type	Fabric Structure		Fabric Specs	Fabric ply No.	Belt width (mm)	Length (m)	Cover Thickness (mm)
	Warp	Weft					Top	Bottom
Cotton			CC56	2-6	400-2200	5-500	2-12	1.5-6
Polyester (EP)	Polyester (E)	Polyamide (P)	EP100	2-6	400-2200	5-500	2-12	1.5-6
			EP125	2-6	400-2200	5-500	2-12	1.5-6
			EP150	2-6	400-2200	5-500	2-12	1.5-6
			EP200	2-6	400-2200	5-500	2-12	1.5-6
			EP250	2-6	400-2200	5-500	2-12	1.5-6
			EP300	2-6	400-2200	5-500	2-12	1.5-6
			EP400	2-6	400-2200	5-500	2-12	1.5-6
			EP500	2-6	400-2200	5-500	2-12	1.5-6
Nylon (NN)	Nylon-66 (N)	Nylon-66 (N)	NN100	2-6	400-2200	5-500	2-12	1.5-6
			NN125	2-6	400-2200	5-500	2-12	1.5-6
			NN150	2-6	400-2200	5-500	2-12	1.5-6
			NN200	2-6	400-2200	5-500	2-12	1.5-6
			NN250	2-6	400-2200	5-500	2-12	1.5-6
			NN300	2-6	400-2200	5-500	2-12	1.5-6
			NN400	2-6	400-2200	5-500	2-12	1.5-6
			NN500	2-6	400-2200	5-500	2-12	1.5-6

Grade	Tensile Strength/Mpa ≥	Breaking Elongation/% ≥	Abrasion Loss/mm3 ≤
H	24	450	120
D	18	400	100
L	15	350	200
DIN W	18	400	90
DIN X	25	450	120
DIN Y	20	400	150
DIN K	20	400	200

Item	Ply to ply	Rubber cover to ply
		Rubber cover thickness ≤1.5mm	Rubber cover thickness >1.5mm
All samples average value/ (N/mm) ≥	4.5	3.2	3.5
All samples min peak value/ (N/mm) ≥	3.9	2.4	2.9
Note: All samples max peak value is not more than 20N/mm.
