Overview

Basic Info.

Model NO.	V belt
Warranty Period	1 Year
Standard or Nonstandard	Standard
Application	Machinery
Feature	Flame-Retardant, Anti-Static
Tensile Strength	Strong
Type	Traction Belt
Applicable Industries	Machinery Repair Shops, Home Use, Auto Parts Facto
Wide	1-100cm
Key Words	Timing Belt
Length	2-2000cm
Transport Package	Carton
Specification	0.001cbm
Trademark	OUDU
Origin	China
HS Code	4010310000
Production Capacity	100000000/Year

Product Description

-Teeth:Auto timing belt enables the belt transmit higher power.
There is one ply of fabric which is used to increase timing belt anti-abrade capability, on the surface of the teeth.

-Low noise when it's running.
Our smooth tooth engagement and direct contact of tooth top with pulley grooves, enable the belt to run quietly even at high speeds. so our good material of auto timing belt keep low noise which can also makes engine running stably with low noise.
-Oil and heat resistance, anti high temperature, resist chemical cauterization by using special chemical material.

Forming and coiling process Vulcanizing process

Grinding process Cardbox package

Hebei OUDU Technology Co.,LTD Why Customer Trust/Choose OUDU Belt?
Product Description Product Property

Property

-- Greater power transmission than classical v belts

-- Suitable for highest loads

-- Temperature range from -50ºC to 120ºC

-- Static conductive to ISO1813
-- Oil,heat,Ozone and abrasion resistant

Structure

Outside fabric: Polyester cotton canvas

Reinforcement: Polyester cord

Rubber: CR

Applications

-- Pumps

-- Fans

-- Blenders

-- Milling plants

-- Drilling machines

-- Autos

-- HVAC systems

-- Compressors

Specification

Type	Top width	Height	Angle
	mm	mm	40°
AVX10	10	8	40°
AVX13	13	9	40°
AVX15	15	9	40°
AVX17	17	11	40°
AVX22	22	13	40°
XPZ	10	8	40°
XPA	13	10	40°
XPB	17	14	40°
XPC	22	18	40°
3VX	9.5	8	40°
5VX	16	13.5	40°
8VX	25.4	23	40°

Trapezoidal Tooth Synchronization Belt

Trapezoidal tooth synchronization belt models
Tooth	Model	pb (mm)	ht (mm)	hs (mm)	β°
inch tooth	MXL	2.032	0.51	1.14	40
	XL	5.08	1.24	2.3	50
	L	9.525	1.91	3.6	40
	H	12.7	2.29	4.3	40
	XH	22.225	6.35	11.2	40
	XXH	31.75	9.53	15.7	40
Metric tooth	T2.5	2.5	0.7	1.3	40
	T5	5	1.2	2.2	40
	T10	10	2.5	4.5	40
	T20	20	5	8	40
	AT5	5	1.2	2.7	50
	AT10	10	2.5	5	50
	AT20	20	5	8	50

HTD ARC Tooth Rubber Timing Belt

Tooth	model	PB(mm)	HT(mm)	HS(mm)
HTD	2M	2	0.75	1.38
	3M	3	1.17	2.4
	5M	5	2.06	3.6
	8M	8	3.38	5.8
	14M	14	6.02	10
	20M	20	8.4	13.2

STD/STS ARC Tooth Rubber Timing Belt

STS/STDArc tooth STS/STD Rubber Belt models
Model	Pb(mm)	Ht(mm)	Hs(mm)	Pitch line(mm)
S2M	2	0.76	1.36	80~3700
S3M	3	1.14	2.3	111~6510
S4.5M	4.5	1.71	2.81	162~1031
S5M	5	1.91	3.4	150~4000
S8M	8	3.05	5.3	376~6640
S14M	14	5.3	10.2	714~5012

RPP/HPPD ARC Tooth Rubber Timing Belt

RPP/HPPDArc tooth RPP/HPPD Rubber Belt Models
Model	Pb(mm)	Ht(mm)	Hs (mm)	Pitchline(mm)
P2M	2	0.76	1.36	112~530
P3M	3	1.15	1.9	174~531
P5M	5	1.95	3.5	300~1100
P8M	8	3.2	5.5	376~2104
P14M	14	6	10	938~3850

Production & Package

Applications

Company Profile

Who Are We -- Rich experience -- 500+ workers -- 100,000 m³ factory area -- 40,000,000$ annual sales

What We Supply --- Conveyor Belt--- Wrapped V Belt --- Cogged V Belt --- Timing Belt --- Poly V Belt

Our Aims --Focus on technology innovation --Green specialist in power transmission --World's leading transissin exterprises

Best Service -- Low MOQ & Fast delivery -- Different OEM to help customer build their brands -- Inquiry will be replied in 2 hours by professional team

Best Service -- Low MOQ & Fast delivery -- Different OEM to help customer build their brands -- Inquiry will be replied in 2 hours by professional team

Multi Styles to Meet Customers' Demands -- Rubber Conveyor Belt/ V Belt/ Timing Belt-- PU Conveyor Belt/ V Belt/ Timing Belt -- Power Transmission Accessaries

Q: Are you a trading company or manufacturer ?

A: We are a manufacturer and have our owned factory

Q: What's your main products?

FAQ 1. Timing belt 2. PK belt 3. V-belt 4. Motor belt 5. Washing machine beltQ: How long is your delivery time? A: Generally it is 3-5 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to quantity.Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge but the cost of freight is not included.Q: Can you print our own logo or brand on my ordered belts? Your own logo and brand is acceptable to be printed on your belts, but with the following advanced requirements: (1) Please send us an authorization to print your logo or brand on your belts; (2) Please provide the design of your logo or brand
